●Description
The Nexys A7 (previously known as the Nexys 4 DDR) is an incredibly accessible, yet powerful, FPGA development board. Designed around the Xilinx Artix-7 FPGA family, the Nexys A7 is a ready-to-use digital circuit development platform that brings industry applications into the classroom environment.Students can start learning right away with the Nexys A7 thanks to its versatile selection of interfaces, such as 10/100 Ethernet, USB, UART, JTAG, and VGA. With a built-in temperature sensor, microphone, and accelerometer, students can work on a variety of projects without needing any additional hardware. Of course, 5 Pmod ports are available for additional customizability and applications.There are two variants of the Nexys A7: The Nexys A7-50T features the XC7A50T-1CSG324C, and the Nexys A7-100T features the larger XC7A100T-1CSG324C.The Nexys A7 is supported by Xilinx's Vivado Design Suite. Both variants of the Nexys A7 are supported by the free WebPACK edition, which helps keep costs down for students.Guides and demos are available to help you get started quickly with the Nexys A7. These can be found through the Support Materials tab.
●Features
・FPGA Features
〇Internal clock speeds exceeding 450MHz
〇On-chip analog-to-digital converter (XADC)
〇Programmable over JTAG and Flash
・System Features
〇USB-JTAG programming circuitry(Micro B USB cableNOT included)
〇Powered from USB or any 7V-15V source
〇microSD card connector
・System Connectivity
〇10/100 Mbps Ethernet
〇USB-UART Bridge
・Interaction and Sensory Devices
〇3-axis accelerometer
〇PDM microphone
〇PWM audio output
〇Temperature Sensor
〇2 four-digit seven-segment displays
〇USB HID for mice, keyboards, and memory sticks
〇16 Switches
〇16 LEDs
〇2 tri-color LEDs
〇12-bit VGA output
・Expansion Connectors
〇4 Pmod connectors
〇Pmod for XADC signals
・Product Compliance:
〇HTC:8471500150
〇ECCN:5A992.c
●What's Included
・Nexys A7 development board
・Digilent custom packaging with protective foam
・Micro USB cable
